Name: High Dielectric Strength Epoxy Resin with H-Class Thermal Stability and Superior Crack Resistance for Electrical Insulation
Brand: Shanghai Wenyou Industry Co., Ltd.
SKU: Se trata de una serie de medidas de seguridad.
Price: 2.50 USD
Availability: InStock

Hogar > productos > Resina epoxi eléctrica >

High Dielectric Strength Epoxy Resin with H-Class Thermal Stability and Superior Crack Resistance for Electrical Insulation

High Dielectric Strength Epoxy Resin

H-Class Thermal Stability Electrical Insulation Resin

Superior Crack Resistance Epoxy Resin System

Lugar de origen:

Porcelana

Nombre de la marca:

WENYOU

Certificación:

REACH/RoHS/UL/ISO/CE

Número de modelo:

Se trata de una serie de medidas de seguridad.

Éntrenos en contacto con

Pida una cita

Detalles del producto

Solicitud:

Aislamiento eléctrico

Característica:

Resistencia al agua, alta calidad

Resistencia al calor:

Alto

Fuerza de impacto:

Alto

Inflamabilidad:

Clase HB

Resistencia química:

Excelente

Pago y términos de envío

Cantidad de orden mínima

20kg

Condiciones de pago

LC, T/T, Western Union, MoneyGram

Productos relacionados

El video

Flame Retardant Epoxy Resin Potting Compound with High Heat Resistance and Excellent Environmental Performance

Consiga el mejor precio

El video

High Dielectric Strength Epoxy Resin with H-Class Thermal Stability and Superior Crack Resistance for Electrical Insulation

Consiga el mejor precio

Flame Retardant UV-Resistant APG Epoxy Resin for High Dielectric Strength Electrical Insulation

Consiga el mejor precio

El video

High Dielectric Strength Electrical Epoxy Resin for Medium & High Voltage Insulation with High Heat and Chemical Resistance

Consiga el mejor precio

Éntrenos en contacto con

008618018933365

Elliot.yang@sh-wysy.com

86-21-64308192

Contacto ahora

Descripción de producto

Epoxy Resin for Indoor High-Voltage Switchgear Bushings Transformers

Product Attributes

Attribute	Value
Application	Electrical Insulation
Feature	Water Resistance, High Quality
Heat Resistance	High
Impact Strength	High
Flammability	HB Class
Chemical Resistance	Excellent

Product Description

The LE-9219K/LH-9219K is a high-performance two-component epoxy resin system designed for medium/high-voltage electrical insulation (12-40.5 kV). Formulated with modified BPA epoxy resin (LE-9219K) and carboxylic anhydride hardener (LH-9219K), it delivers exceptional thermal shock resistance, superior crack resistance, and H-class thermal stability (IEC 60085). Ideal for vacuum casting or APG processes, it ensures reliability in critical indoor electrical components.

Key Features & Advantages

Feature	Advantage
Modified BPA Epoxy + Anhydride Hardener	Enhanced thermal stability & mechanical strength
Optimized for Vacuum Casting/APG	Flexible processing, adaptable to client production methods
Superior Crack Resistance	Withstands thermal cycling, reducing failure risks
HB Flammability Rating (UL94)	Meets strict safety standards for electrical applications
High Dielectric Strength	≥25 kV/mm (1mm thickness, IEC 60243-1)
Low Water Absorption	0.10-0.20% (23°C/10 days) for long-term insulation integrity
H-Class Thermal Endurance	Sustained performance up to 150°C

Applications

Perfect for insulating components in indoor high-voltage systems:

Switchgear contact boxes (12-40.5 kV)
Bushings, insulators, & encapsulation
Transformers, sensors, & circuit breakers
HV insulation products requiring precision casting

Key Performance Data

Cured system: LE-9219K/LH-9219K/Silica powder = 100:100:350 @ 140°C/10h

Property	Value	Standard
Glass Transition Temp (Tg)	105-120°C	ISO 11357-2
Tensile Strength	65-85 MPa	ISO 527
Flexural Strength	105-140 MPa	ISO 178
Volume Resistivity	10¹⁵ Ω*cm	IEC 62631-3-1
Arc Resistance	181-198 sec	IEC 61621
Breakdown Strength	≥25 kV/mm	IEC 60243-1
Dielectric Constant	3.0-4.0 (50Hz)	IEC 60250
Water Absorption	0.10-0.20% (23°C/10d)	ISO 62
Tracking Resistance	≥600 V	IEC 60112
Curing Shrinkage	0.8-1.0%	HG/T2625

Frequently Asked Questions (FAQ)

Q1: What is the mix ratio for LE-9219K/LH-9219K?

A: Standard ratio is 100:100 pbw (resin:hardener). Filler (silica powder) added at 300-380 pbw.

Q2: How should the hardener be stored?

A: Store in sealed containers at 6-35°C. Avoid moisture exposure. If crystallized, preheat to 70-80°C and stir before use.

Q3: What curing process is recommended?

A: Two options:
Vacuum Casting: Cure 70-80°C/3-5h + 90-100°C/2-4h; Post-cure 130°C/12h.
APG: Mold temp 130-160°C; Post-cure 130-150°C/10-12h.

Q4: Is this system suitable for outdoor use?

A: Designed for indoor electrical insulation only. Hydrophobicity class HC1 (IEC TS 62073).

Q5: What safety measures are required during handling?

A: Mandatory: gloves, goggles, protective clothing. Use ventilation (3-5 air renewals/hour). Avoid skin contact--wash immediately if exposed.
